Маршрутизатор Cisco C2951-VSEC-CUBE/K9
Производитель: Cisco
Артикул: C2951-VSEC-CUBE/K9
Срок поставки: по запросу
Цена по запросу
Уточните условия поставки у менеджера.
Описание
C2951 UC SEC CUBE Bundle, PVDM3-32, UC SEC Lic, FL-CUBEE-25 Сервисный контракт Cisco SMARTnet (8x5xNBD) для данного устройства: CON-SNT-2951VSCC АКТУАЛЬНАЯ ЗАМЕНА: Маршрутизатор Cisco ISR4351-VSEC/K9
| General | |
|---|---|
| Device Type | Router |
| Enclosure Type | Rack-mountable - modular - 2U |
| Connectivity Technology | Wired |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Capacity | Cisco Unified SRST sessions : 250 Cisco Unified Communications Manager Express sessions : 150 |
| Network / Transport Protocol | IPSec, PPPoE, L2TPv3 |
| Routing Protocol | OSPF, IS-IS, BGP, EIGRP, DVMRP, PIM-SM, static IP routing, IGMPv3, GRE, PIM-SSM, static IPv4 routing, static IPv6 routing, policy-based routing (PBR), MPLS, Bidirectional Forwarding Detection (BFD), IPv4-to-IPv6 Multicast |
| Remote Management Protocol | SNMP, RMON, TR-069 |
| Encryption Algorithm | DES, Triple DES, AES, SSL |
| Features | Firewall protection, hardware encryption, VPN support, MPLS support, Syslog support, content filtering, IPv6 support, Intrusion Prevention System (IPS), Class-Based Weighted Fair Queuing (CBWFQ), Weighted Random Early Detection (WRED), Access Control List (ACL) support, Quality of Service (QoS), Dynamic Multipoint VPN (DMVPN), Web Services Management Agent (WSMA), NetFlow |
| Compliant Standards | IEEE 802.3, IEEE 802.1Q, IEEE 802.3af, IEEE 802.3ah, IEEE 802.1ah, IEEE 802.1ag, ANSI T1.101, ITU-T G.823, ITU-T G.824 , CISPR 22 Class A, CISPR 24, EN55024, EN55022 Class A, EN50082-1, AS/NZS 60950-1, ICES-003 Class A, CS-03, R&TTE, FCC CFR47 Part 15, EN300-386, UL 60950-1, IEC 60950-1, EN 60950-1, BSMI CNS 13438, AS/NZS 3548 Class A, CAN/CSA C22.2 No. 60950-1, VCCI V-3, EN 61000, TIA/EIA/IS-968 |
| RAM | 512 MB (installed) / 2 GB (max) - DDR2 SDRAM |
| Flash Memory | 256 MB (installed) / 8 GB (max) |
| Status Indicators | Link activity, power |
| Communications | |
| Type | Voice / fax module |
| Digital Ports Qty | 32 |
| IP Telephony | |
| Voice Codecs | G.711, G.722, G.723.1, G.728, G.729, G.729a, G.729ab, G.726, G.729b |
| Expansion / Connectivity | |
| Interfaces | WAN : 3 x 10Base-T/100Base-TX/1000Base-T - RJ-45 Management : 1 x console - RJ-45 Management : 1 x console - mini-USB Type B Serial : 1 x auxiliary - RJ-45 USB : 2 x 4 pin USB Type A 1 x SFP (mini-GBIC) |
| Expansion Slots | 4 (total) / 4 (free) x EHWIC 3 (total) / 2 (free) x PVDM 2 (total) / 1 (free) x CompactFlash 1 (total) / 1 (free) x ISM |
| Power | |
| Power Device | Internal power supply |
| Voltage Required | AC 120/230 V ( 50/60 Hz ) |
| Miscellaneous | |
| Rack Mounting Kit | Included |
| Software / System Requirements | |
| OS Provided | Cisco IOS Universal |
| Software Included | Cisco IOS IP Base, Cisco IOS Unified Communications, Cisco IOS Security, Cisco Unified Border Element (25 sessions) |
| Dimensions & Weight | |
| Approximate Width | 17.3 in |
| Approximate Depth | 18.5 in |
| Approximate Height | 3.5 in |
| Approximate Weight | 29.1 lbs |
| Manufacturer Warranty | |
| Service & Support | 90 days warranty |
| Service & Support Details | Limited warranty - advance parts replacement - 90 days - response time: 10 days |
| Environmental Parameters | |
| Min Operating Temperature | 32 |
| Max Operating Temperature | 104 |
| Humidity Range Operating | 5 - 85% |
| Производитель | Cisco |
| EOS | 09.12.2017 |
Характеристики
- Approximate Depth
- 18.5 in
- Approximate Height
- 3.5 in
- Approximate Weight
- 29.1 lbs
- Approximate Width
- 17.3 in
- Capacity
- Cisco Unified SRST sessions : 250 Cisco Unified Communications Manager Express sessions : 150
- Compliant Standards
- IEEE 802.3, IEEE 802.1Q, IEEE 802.3af, IEEE 802.3ah, IEEE 802.1ah, IEEE 802.1ag, ANSI T1.101, ITU-T G.823, ITU-T G.824 , CISPR 22 Class A, CISPR 24, EN55024, EN55022 Class A, EN50082-1, AS/NZS 60950-1, ICES-003 Class A, CS-03, R&TTE, FCC CFR47 Part 15, EN300-386, UL 60950-1, IEC 60950-1, EN 60950-1, BSMI CNS 13438, AS/NZS 3548 Class A, CAN/CSA C22.2 No. 60950-1, VCCI V-3, EN 61000, TIA/EIA/IS-968
- Connectivity Technology
- Wired
- Data Link Protocol
- Ethernet, Fast Ethernet, Gigabit Ethernet
- Device Type
- Router
- Digital Ports Qty
- 32
- Enclosure Type
- Rack-mountable - modular - 2U
- Encryption Algorithm
- DES, Triple DES, AES, SSL
- EOS
- 09.12.2017
- Expansion Slots
- 4 (total) / 4 (free) x EHWIC 3 (total) / 2 (free) x PVDM 2 (total) / 1 (free) x CompactFlash 1 (total) / 1 (free) x ISM
- Features
- Firewall protection, hardware encryption, VPN support, MPLS support, Syslog support, content filtering, IPv6 support, Intrusion Prevention System (IPS), Class-Based Weighted Fair Queuing (CBWFQ), Weighted Random Early Detection (WRED), Access Control List (ACL) support, Quality of Service (QoS), Dynamic Multipoint VPN (DMVPN), Web Services Management Agent (WSMA), NetFlow
- Flash Memory
- 256 MB (installed) / 8 GB (max)
- Humidity Range Operating
- 5 - 85%
- Interfaces
- WAN : 3 x 10Base-T/100Base-TX/1000Base-T - RJ-45 Management : 1 x console - RJ-45 Management : 1 x console - mini-USB Type B Serial : 1 x auxiliary - RJ-45 USB : 2 x 4 pin USB Type A 1 x SFP (mini-GBIC)
- Max Operating Temperature
- 104
- Min Operating Temperature
- 32
- Network / Transport Protocol
- IPSec, PPPoE, L2TPv3
- OS Provided
- Cisco IOS Universal
- Power Device
- Internal power supply
- Rack Mounting Kit
- Included
- RAM
- 512 MB (installed) / 2 GB (max) - DDR2 SDRAM
- Remote Management Protocol
- SNMP, RMON, TR-069
- Routing Protocol
- OSPF, IS-IS, BGP, EIGRP, DVMRP, PIM-SM, static IP routing, IGMPv3, GRE, PIM-SSM, static IPv4 routing, static IPv6 routing, policy-based routing (PBR), MPLS, Bidirectional Forwarding Detection (BFD), IPv4-to-IPv6 Multicast
- Service & Support
- 90 days warranty
- Service & Support Details
- Limited warranty - advance parts replacement - 90 days - response time: 10 days
- Software Included
- Cisco IOS IP Base, Cisco IOS Unified Communications, Cisco IOS Security, Cisco Unified Border Element (25 sessions)
- Status Indicators
- Link activity, power
- Type
- Voice / fax module
- Voice Codecs
- G.711, G.722, G.723.1, G.728, G.729, G.729a, G.729ab, G.726, G.729b
- Voltage Required
- AC 120/230 V ( 50/60 Hz )
- Производитель
- Cisco
Спецификации
Подробную спецификацию предоставим по запросу. Укажите необходимые интерфейсы, производительность и условия эксплуатации.
Загрузки
Документы для скачивания пока не добавлены. Запросите инструкцию или технический паспорт у менеджера.
